| 产品规格及说明 | |
|---|---|
| 设备品牌：帝龙 | 设备型号：3021-20 |
| 订购价格：电话/面议 | 交货日期：3~30/工作日 |
| 产地:东莞 | 是否进口:否 |
| 加工定制:否 | 功率密度:80 |
| 总功率:2.2KW | 重量:60（Kg） |
| UV主峰波长:365 | 用途:UV胶水固化 |
| 是否跨境出口专供货源:否 | |
| 产品标签：uv胶水固化,uv胶焊点保护,焊点保护专用uv胶,排线焊点保护uv胶,焊点保护uv固化胶,焊点保护uv胶线束,焊点保护uv胶专用uv固化机 | |
| 咨询热线：13715339029 | 售后服务：13715339029 |
| 技术咨询：13715339029 |  QQ咨询：260200500 |
–equipment model:4012-30
Exergy applicable scope: ultraviolet UV light curing, UV glue UV curing, UV curing varnish and wooden floor, wooden doors, furniture of UV coating, UV roll coating, UV coating, UV curing and drying, or used alone.
– performance characteristics: wide format, strong load-carrying ability, practical.
UV lamp: lamp lamp lamp;
UV lamp adjustment: each lamp height, angle individually adjust;
UV lamp is designed, and the curing is uniform;
Forced air cooling, to ensure that the UV room temperature is appropriate;
The replacement of UV lamp adopts closed door device, which is simple and easy to maintain.
– Technical parameters:
Power requirements: single phase three line 220VAC (power frequency AC) 50HZ (Hz)
Power: about 2.2KW (kw)
Dimensions: 1330 L (long) x 520W (wide) x mm (high) 1480H
Conveyor speed: m/min 0-30 (M / min)
Conveyor width: 300mm (mm)
Belt material: Teflon high-temperature net belt, supporting power roller
Cooling method: forced air cooling
Light source: high pressure mercury lamp type Hg
Lamp power: 80w/cm
Source configuration: *2 1KW.
Tube length: 400MM
The life of the light source: according to the equivalent test, the average more than 1000 hours (H), attenuation of not less than 80%.
Peak wavelength: 365nm (nm)
Typical features: aluminum reflector, multi angle curing, suitable for a certain thickness of the product
Typical application: UV UV furniture paint curing, UV curing, adapted to the non explosion proof requirements.
– Application: mobile phone shell UV ink, glue curing etc..
