可通过触摸屏实现以下功能
1、PLC触摸屏、冷光镜、三色指示灯、 不锈钢包边防紫外树脂遮光门;
2、75%~100%两档调光;
3、适时调整网带运转速度及UV灯高度;
4、显示UV灯使用时间,便于掌握灯管的更换情况;
5 、各种安全保护功能,在出现故障后自动作出相应处理,并显示故障原因及排除方法,及时解决问题。
Feature:
The following functions could be reached through touch screen
1. PLC touch screen, cold light mirror, tricolor indicator, and stainless steel rim with UV proof resin shutter door;
2. Two degrees of light modulation from 75%~100%;
3. It can adjust the speed of mesh belt and UV light height timely;
4. It can display the use time of UV lamp, easy to grasp the replacement condition of the lamp tube;
5. There are various safety protection functions, which can automatically make the appropriate processing in the presence
of fault, and display the cause of failure and troubleshooting, to timely solve the problem.
附助功能 Auxiliary Function :
PLC触摸屏、冷光镜、三色指示灯、 不锈钢包边防紫外树脂遮光门。
PLC touch screen, cold light mirror, tricolor indicator, and stainless steel rim with UV proof resin shutter.
适用范围 Using Range :
粘接:电路板元件、玻璃粘胶、电子元件、液晶片、端子胶封;
木涂装: 材、玻璃、纸张、塑胶、金属表面喷涂上光;
印刷:网版、平版、凸版印刷 。
Bonding : component of circuit board, glass viscose, electric component, LED film, and terminal seal;
Painting : wood, glass, paper, plastic, and surface polishing of metal;
Pint : halftone, lithography, and relief printing.
技术参数 Technical Parameters:
UV灯数量 2pcs
输送速度 0~20m/min
功率密度 90 W/cm
电源 380V
UV灯功率 3kw
有效照射宽度 400mm
UV主峰波长 365nm
总功率 6.8kw
外形尺寸 L2000×W670×H1350mm
